V Shaped Slotting Mode Automatic Channel Letter Bending Machine Closed Loop Control System
V-shaped Slotting Mode,Closed Loop Control System Auto Channel Letter Bender
Description
Perfect Laser specializes in R & D and production of automatic word machine, first-class quality, global service. Automatic cutting tooth bending machine is composed of laser Charles letters for nearly twenty years of rich experience in production research and design of high quality and advanced products. PEL-800 Auto Channel Letter Bender for Trim Cap Aluminum Letters has the advantages of convenient operation, the machine has low energy consumption, durable, functional, high-grade stainless steel square landscape characters, words, words, words, punching resin giant light preferred high-end equipment side word.
Product Features
1. Germany imported high hardness special stainless steel slotting tools, slotting more perfect and more accurate, the tool can be used repeatedly, greatly saving the production cost.
2. Advanced retractable double bent structure, can reduce bending scratch, avoid bending process interference, improve bending moment;
3. High precision, built-in material tracking encoder and feed length closed loop detection, to ensure the finished product and the original file length deviation in the controllable range, consistency and molding degree is high;
4. The structure is simple and compact, the body rigidity is good. The mechanical block can be adjusted at any time, so it can meet the requirements of free bending;
5. Using servo control mold stamping cutting mechanism, make the machine performance more stable, no oil, running noise is small, etc.
Application
This machine has the advantages of high productivity and high bending of sheet working precision, die adopts different shapes, can be bent into various shapes, the slide once on the sheet for a bending workpiece, after repeated bending can get more complicated, when equipped with the appropriate equipment, but also as for punching. Apply to the advertising industry.
Specifications
Model: | PEL-800 Channel Letter Bender |
Power supply | AC 200V |
Power | 4.0 KW |
Compressed air | 0.4-0.6 MPa |
Control axis quantity | 5 axis |
Min. Bending radius | R7mm |
Min. Distance between
interior angle and exterior angle | 4.5mm |
Bending distance from start | 3mm |
Applied material | Stainless steel, Galvanized sheet, Aluminum coil |
Material thickness | 0.6-1.0mm |
Processing height | Stainless steel, Galvanized sheet (20-175mm) ;aluminum
coil (50-175mm) |
Material feeding method | Alternating double screw rails feeding |
Notching type | Controlled by servo motor |
Notching angle | 30°/120° |
Flanging type | Pneumatic flanging for right angle |
Flanging width | 14mm |
Servo motor | 4PCs |
Step motor | 1PCs |
N.W./G.W. | 800Kgs/900Kgs |
Dimension | 2290(L)*860(W)*1560(H)mm |
Software support | DXF/PLT files input, support CAD, TYPE3, CRELDRAW,
ILLUSTRATOR, ect. |
Sample Show
Packaging & Delivery
1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
Competitive Advantages
1. We offer high quality products at competitive price in quick delivery.
2. 100% custom pass guaranteed.
3. Good after-sale service.
4. Flexible and Untraceable payment terms.
5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
